TECHNICAL PARAMETER:

Optical system

- Light source: 1x 350W Red, Green, Blue, White,Amber, Lime

- Average lifespan: 20,000 hours

- Color temperature: (the entire lamp color temperature channel is adjustable from 2000-10.000K)

- Color rendering index: 95 @ 2800K

- Light output of the whole machine: 10215LM

- Beam angle: 55° Flood angle of the whole lamp: 87 degrees

Effect

- Uniform RGBWAL color mixing system

- Fast electronic strobe 1 ~ 25 Hz

- Refresh rate: 800 ~ 25K Hz (800Hz, 1.200Hz, 2.000Hz, 3.600Hz, 12kHz, 25kHz)

- Dimming delay: three types

- Dimming curve: four types

software

- Software update via DMX signal for quick and easy upgrade

- Intelligent temperature protection to ensure the life of LED lamp beads

- 0~100% dimming

Control and programming

-Protocol: Standard DMX512 /RDM protocol

- Data connection: three-core or five-core signal line input/output (XLR 5-pin),

- DMX channel: 1CH/2CH/3CH/4CH/6CH/7CH/13CH/21CH/RGB10CH/RGB15CH/CMY10CH/CMY15CH

- Display: OLED display

Lamp structure and heat dissipation

- Magnesium-aluminum alloy structure

- Speed-adjustable low-noise waterproof fan with forced convection cooling

- Unlimited splicing

Power

- Input voltage: AC 100V ~ 240V 50/60Hz

- Rated power of the whole lamp: 300W Power factor: 0.95F Input current: 1.45A 220V

- Power connection: Waterproof power cord input (TRUE1)

- Maximum power: 350W

- Constant power: 180W

other

-Protection level: IP65

- Working environment: -15℃～ 45℃

- Starting environment: -15℃～ 45℃

SIZE

- SIZE：216 x 213 x 151mm

- WEIGHT：2.35kg
